Data Center Solutions
Premium Data Center Cable Whip Assemblies
Series: DC-WHIP | Revision: 2.0 | Date: 2026
PREMIUM
Data Center Grade
Black LFMC • Gold Brass Fittings
99.9% Oxygen-Free Copper
Black LFMC • Gold Brass Fittings
99.9% Oxygen-Free Copper
Why Choose Our DC Whips?
100% factory tested with megger reports
99.9% oxygen-free copper conductors
Premium gold brass fittings - professional appearance
Custom lengths available (6ft-25ft)
Proper color-coded wiring per NEC
Pre-labeled with voltage & amperage
Continuous ground path verified
2-year warranty on materials & workmanship
Typical Applications
Server Racks
PDU Connections
CRAC Units
UPS Systems
Construction Specifications
| Conduit Type | Liquid-Tight Flexible Metal (LFMC) |
| Core Material | Galvanized Steel Interlocking Armor |
| Jacket Material | Black PVC - Flame Retardant |
| Conductor Material | 99.9% Oxygen-Free Copper |
| Wire Insulation | THHN/THWN-2 (90°C Rated) |
| Fittings Material | Natural Brass (Gold) or Nickel-Plated |
| Terminal Lugs | Tin-Plated Copper Compression |
| Grounding | Continuous Path, Bonded Fittings |
Electrical Ratings
| Voltage Rating | 600V AC/DC Maximum |
| Common Voltages | 208V, 240V, 480V (3-Phase) |
| Amperage Range | 30A, 60A, 100A, 200A |
| Temperature Rating | 90°C (194°F) Continuous |
| Operating Temp Range | -20°C to +90°C (-4°F to +194°F) |
| Configuration | 3-Phase + Neutral + Ground (5-Wire) |
Standard Product Configurations
| Part Number | Amp | Voltage | Wire | Length |
|---|---|---|---|---|
| DC-WHIP-30A-208V-10FT | 30A | 208V 3Ø | 10 AWG | 10 ft |
| DC-WHIP-60A-208V-10FT | 60A | 208V 3Ø | 6 AWG | 10 ft |
| DC-WHIP-100A-208V-10FT | 100A | 208V 3Ø | 2 AWG | 10 ft |
| DC-WHIP-60A-480V-15FT | 60A | 480V 3Ø | 6 AWG | 15 ft |
| DC-WHIP-100A-480V-15FT | 100A | 480V 3Ø | 4 AWG | 15 ft |
| DC-WHIP-CUSTOM | Custom configurations available - contact us | |||
Standards & Certifications
UL 360 LISTED
NEC ARTICLE 350
NFPA 75
RoHS COMPLIANT
FACTORY TESTED
| NEC Compliance | Article 350 (LFMC) |
| Fire Rating | Flame Retardant PVC Jacket |
| Quality Testing | Megger, Continuity, Visual Inspection |
| Documentation | Test Reports Included w/ Each Whip |
